OEM Hollow Shaft Right Angle Motor Gearbox Planetary Reducer

  • 1
  • 2

Brand Name : Giant Precision

Model Number : NBR Series Planetary Gearboxes

Certification : ISO9001

Place of Origin : Jiangsu, China

MOQ : 1 set

Price : To Be Negotiated

Payment Terms : T/T

Supply Ability : 20000 Sets per Month

Delivery Time : 3-4 Weeks

Packaging Details : Carton Box

Product : NBR Series Planetary Gearboxes

Model : NBR060, NBR090, NBR115, NBR142, NBR180, NBR220

Ratio : 3 to 200

Segment : Single, Double

Efficiency : ≥95%

Service Life : 20000 hours

Continuous Operation : 10000 hours

Protection Class : IP65

Operating Temperature : -10℃-90℃

Ultraprecise backlash : ≤4 arcmin

Application : laser cutting，manipulator，printing equipment，automobile manufacturing, satellite communications, pharmaceutical industry

Warranty : 1 Year

Contact Now

OEM Hollow Shaft Right Angle Motor Gearbox Planetary ReducerOEM Hollow Shaft Right Angle Motor Gearbox Planetary Reducer

Specification Segment number Ratio NBR060 NBR090 NBR115 NBR142 NBR180 NBR220
Rated output torque Nm single 3 50 120 190 320 550 1080
4 45 130 270 510 990 1610
5 55 150 310 610 1140 1900
6 50 140 290 570 1040 1800
7 45 130 280 520 1040 1710
8 40 110 240 470 950 1520
9 35 95 210 420 850 1420
10 35 95 210 420 850 1420
12 50 140 290 570 1040 1800
14 45 130 280 520 1040 1710
16 40 110 240 470 950 1520
20 35 95 210 420 850 1420
double 15 50 120 190 320 550 1080
16 — — — — 990 1610
25 55 150 310 610 1140 1900
30 50 120 190 320 550 1080
35 55 150 310 610 1140 1900
40 55 150 310 610 1140 1900
45 55 150 310 610 1140 1900
50 55 150 310 610 1140 1900
60 55 150 310 610 1140 1900
70 55 150 310 610 1140 1900
80 55 150 310 610 1140 1900
90 55 150 310 610 1140 1900
100 55 150 310 610 1140 1900
120 50 140 290 570 1040 1800
140 45 130 280 520 1040 1710
160 40 110 240 470 950 1520
180 35 95 210 420 850 1420
200 35 95 210 420 850 1420
Rotary inertia Kg.cm3 single 3 0.35 2.25 6.84 23.40 68.90 152.09
4 0.35 2.25 6.84 23.40 68.90 152.09
5 0.35 2.25 6.84 23.40 68.90 152.09
6 0.35 2.25 6.84 23.40 68.90 152.09
7 0.35 2.25 6.84 23.40 68.90 152.09
8 0.35 2.25 6.84 23.40 68.90 152.09
9 0.35 2.25 6.84 23.40 68.90 152.09
10 0.35 2.25 6.84 23.40 68.90 145.82
12 0.35 2.25 6.84 23.40 68.90 145.82
14 0.7 1.87 6.25 21.80 65.60 145.82
16 0.7 1.87 6.25 21.80 65.60 145.82
20 0.7 1.87 6.25 21.80 65.60 145.82
double 15.00 0.09 0.35 2.25 6.84 23.40 68.90
16 — — — — 23.40 68.90
25 0.09 0.35 2.25 6.84 23.40 68.90
30 0.09 0.35 2.25 6.84 23.40 68.90
35 0.09 0.35 2.25 6.84 23.40 68.90
40 0.09 0.35 2.25 6.84 23.40 68.90
45 0.09 0.35 2.25 6.84 23.40 68.90
50 0.09 0.35 2.25 6.84 23.40 68.90
60 0.09 0.35 2.25 6.84 23.40 68.90
70 0.09 0.35 2.25 6.84 23.40 68.90
80 0.09 0.35 2.25 6.84 23.40 68.90
90 0.09 0.35 2.25 6.84 23.40 68.90
100 0.09 0.35 2.25 6.84 23.40 68.90
120 0.09 0.31 1.87 6.25 21.80 65.60
140 0.09 0.31 1.87 6.25 21.80 65.60
160 0.09 0.31 1.87 6.25 21.80 65.60
180 0.09 0.31 1.87 6.25 21.80 65.60
200 0.09 0.31 1.87 6.25 21.80 65.60

OEM Hollow Shaft Right Angle Motor Gearbox Planetary Reducer

OEM Hollow Shaft Right Angle Motor Gearbox Planetary Reducer

OEM Hollow Shaft Right Angle Motor Gearbox Planetary Reducer

OEM Hollow Shaft Right Angle Motor Gearbox Planetary Reducer

OEM Hollow Shaft Right Angle Motor Gearbox Planetary Reducer

OEM Hollow Shaft Right Angle Motor Gearbox Planetary Reducer

Parameters Table Segment number Ratio NBR060 NBR090 NBR115 NBR142 NBR180 NBR220
Max acceleration torque Nm 1,2 1.8 times rated output torque
Emergency stop torque Nm 1,2 3 times rated output torque
Rated input speed rmp 1 3~20 5000 4000 4000 3000 3000 2000
2 15~200 5000 4000 4000 3000 3000 2000
Max input speed rmp 1 3~20 10000 8000 8000 6000 6000 4000
2 15~200 10000 8000 8000 6000 6000 4000
Ultraprecise backlash arcmin 1 3~20 — ≤2 ≤2 ≤2 ≤2 ≤2
2 15~200 — ≤4 ≤4 ≤4 ≤4 ≤4
Precise backlash arcmin 1 3~20 ≤4 ≤4 ≤4 ≤4 ≤4 ≤4
2 15~200 ≤7 ≤7 ≤7 ≤7 ≤7 ≤7
Standard backlash arcmin 1 3~20 ≤6 ≤6 ≤6 ≤6 ≤6 ≤5
2 15~200 ≤9 ≤9 ≤9 ≤9 ≤9 ≤7
Orsional rigidity Nm/arcmin 1,2 3~200 8 14 27 52 148 305
Max. radial Force N 1,2 3~200 1730 3250 7000 9600 14500 27800
Max. axial Force N 1,2 3~200 865 1625 3500 4800 7250 13900
Tilting moment Nm 1,2 3~200 77 152 325 530 920 1840
Service Life hr 1,2 3~200 20000hr(continuous operation 10000hr)
Efficiency % 1 3~20 ≥95%
% 2 15~200 ≥92%
Weight kg 1 3~20 2.1 6.4 13.0 24.5 51.0 83.0
kg 2 15~200 2.1 7.8 14.2 27.5 54.0 95.0
Operating Temperature ℃ 1,2 3~200 -10℃-90℃
Lubrication 　 1,2 3~200 Synthetic grease
Protection Class 　 1,2 3~200 IP65
Mounting Position 　 1,2 3~200 Any direction
Noise Level (N1=3000rpm,Non-Loaded) dB(A) 1 3~20 ≤63 ≤65 ≤68 ≤70 ≤72 ≤74
2 15~200 ≤63 ≤65 ≤68 ≤70 ≤72 ≤74
